PDQ30-Q24-S5-D
Manufacturer:
Same Sky
Mfr.Part #:
PDQ30-Q24-S5-D
Datasheet:
Description:
DC to DC Converters DIP-6 Module Through Hole Nominal Input Voltage:9 V to 36 V Min Input Voltage:9 V Max Input Voltage:36 V 90 %
| Parameter | Value |
|---|---|
| Length | 25.4 mm |
| Width | 25.4 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Height | 10.2 mm |
| Packaging | Bulk |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Features | OCP, OTP, OVP, SCP, UVLO |
| Min Input Voltage | 9 V |
| Max Power Dissipation | 30 W |
| Max Output Current | 6 A |
| Max Input Voltage | 36 V |
| Number of Outputs | 1 |
| Isolation Voltage | 1 kV |
| Output Power | 30 W |
| Efficiency | 90 % |
| Voltage - Output 1 | 5 V |
| Nominal Input Voltage | 9 V to 36 V |
| Schedule B | 8542390000 |
| Output Current-Channel 1 | 6 A |
| Output Voltage-Channel 1 | 5 V |
Stock: 485
Distributors
pcbx
pcbxUnit Price$29.63870
Ext.Price$29.63870
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $29.63870 | $29.63870 |
| 10 | $28.97205 | $289.72050 |
| 25 | $28.32040 | $708.01000 |
| 50 | $27.68340 | $1384.17000 |
| 100 | $27.06073 | $2706.07300 |
| 300 | $26.45207 | $7935.62100 |
| 500 | $25.85710 | $12928.55000 |
| 1000 | $25.27600 | $25276.00000 |
